CSDP-Ceiling Slot Diffuser - Plaster

UNAVAILABLE

Currently under redevelopment. Please contact your local branch for further details.

Extruded aluminium continuous or discrete length linear slot diffusers to suit modern interiors, while providing unobtrusive draftless air distribution over widely ranging airflows. The CSDP is plastered directly into the ceiling to provide a fully seamless finish.
The CSDP provides identical performance to the existing flanged CSD range and includes a serrated wing to assist with plastering into the ceiling.

Blends seamlessly into the ceiling.
No visible flange.
Available in one to four slots with three slot widths.
Standard universal pattern control is aluminium, black anodised for best visual effect and can be adjusted to give full 180° control of air pattern, with volume control to shut off.
Utilises the CSD-MF mounting frame available for ease of installation and high standard finish.
For use with diffuser adapter CSDA/I, plenum supply, or linear duct.
Alignment strips and four end treatments to suit discrete or continuous lengths.
Available in single piece lengths up to 2.9 metres.

CSDPCeiling Slot Diffuser – Plaster

CSDP
Ceiling Slot Diffuser – Plaster
